| Model: | EG8120L |
| Dimensions (H x W x D): | 30 mm x 115 mm x 94 mm |
| Weight: | 250g |
| Operating Temperature: | 0°C to 40°C |
| Operating Humidity: | 5% RH to 95% RH (non-condensing) |
| Model | EG8120L |
| Dimensions (H x W x D) | 30 mm x 115 mm x 94 mm |
| Weight | 250g |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | 5% RH to 95% RH (non-condensing) |
| Power Adapter Input | 100 V to 240 V AC, 50 Hz/60 Hz |
| System Power Supply | 11 V to 14 V DC, 0.5 A |
| Ports | 1GE 1FE 1TEL |
| Optical Connector | SC/UPC, CLASS B+ |
| PON Interface | 1 GPON interface,Downstream rate 2.5Gbps,Upstream rate 1.25Gbps |
| LAN Interface | 1 x 10/100/1000Mbps(GE) and 1x 10/100Mbps(FE) auto adaptive Ethernet interfaces. Full/Half, RJ45 connector |
| WLAN Module | External dual antenna, antenna gain 5db, antenna power 16~21dbm ;Support 2.4GHz, 300M transmission rate |
| Capability | Support NAT/PPPOE/DHCP/Static IP/Bridge WAN |
| Wavelength | TX: 1310nm, RX: 1490nm |
