| Product Name: | 10G SFP+ SR 850nm 300m LC DDM Transceivers |
| Product No: | SFP-XGMM85-3HD |
| Date Rate: | 10G |
| Wavelength: | 850nm |
Overview
10G SFP+ SR 850nm 300m LC DDM Transceivers
SFP-10G-SR is a hot-swappable input/output device that plugs into aGigabit Ethernet port or slot, linking the port with the network. SFPs can be used and interchanged on a wide variety of switches and routers, There are also many other advantages such as isolation protection, good data security, working stability and easy maintenance.
【 Specification 】
Main Feature:
*Supports up to 10.7Gbps bit rates
*Hot-pluggable SFP+ footprint
*850nm VCSEL laser and PIN photodiode, Up to 300m for OM3-MMF transmission
*Compliant with SFP+ MSA and SFF-8472 with duplex LC receptacle
*Compatible with RoHS
*Single +3.3V power supply
*Real Time Digital Diagnostic Monitoring
*Operating case temperature:Standard: 0 to +70°C
Industrial: -40 to +85°C
| Product Name | 10G SFP+ SR 850nm 300m LC DDM Transceivers |
| Product No | SFP-XGMM85-3HD |
| Date Rate | 10G |
| Wavelength | 850nm |
| Source | VCSEL + PIN |
| Temperature | 0 to 70°C (32 to 158°F) |
| TX Power | -6.5~-0.5dBm |
| Receiver Sensitivity | < -11.1dBm |
| Media Type | MMF |
| Connector | LC Duplex |
| DDM/DOM | Supported |
| Reach | 300m |
