| Product Name: | 10/100/1000Mbps Copper SFP 100m Transceivers |
| Product No: | SFP-GEM-TD |
| Date Rate: | 10/100/1000Mbps |
| Cable Distance: | 100m |
Overview
10/100/1000BASE-T Copper 100m RJ45 SFP
SFP-1G-T Copper Small Form Pluggable (SFP) transceivers are based on the SFP Multi Source Agreement (MSA)1. They are with the Gigabit Ethernet and SFP-1G-T standards as specified in IEEE Std 802.3z2 and IEEE Std 802.3ab3. The SFP-1G-T physical layer IC (PHY) can be accessed via I2C, allowing access to all PHY settings and features.
Specification
Feature
•Up to 1.25Gb/s bi-directional data links .
•Hot-pluggable SFP footprint .
•Extended case temperature range .
•Fully metallic enclosure for low EMI.
•Low power dissipation .
•Compact RJ-45 connector assembly .
•Access to physical layer IC via 2-wire serial bus .
•1000 BASE-T operation in host systems with SERDES interface.
•10/100/1000Mbps compliant in host systems with SGMII interface.
| Product No | SFP-GEM-TD |
| Product Name | 10/100/1000Mbps Copper SFP 100m Transceivers |
| Date Rate | 10/100/1000Mbps |
| Form Factor | SFP |
| Power Consumption | < 1W |
| Cable Type | RJ45 |
| Media | Cat 6/Cat 6a |
| Temperature | 0 to 70°C (32 to 158°F) |
| Connector | RJ-45 |
| DDM/DOM | Not Supported |
| Cable Distance | 100m |
