| Product Name: | 1000BASE-T SFP Transceiver Module (Copper, 100m, RJ-45) |
| Product No: | SFP-GES-TD |
| Date Rate: | 1000Mbps |
| Cable Distance: | 100m |
Overview
1000BASE-T Copper 100m RJ45 SFP
SFP-GES-TD Copper Small Form Pluggable (SFP) transceivers are based on the SFP Multi Source Agreement (MSA)1. They are with the Gigabit Ethernet and SFP-GES-TD standards as specified in IEEE Std 802.3z2 and IEEE Std 802.3ab3. The SFP-GES-TD physical layer IC (PHY) can be accessed via I2C, allowing access to all PHY settings and features.
Specification
Feature:
•Up to 1.25Gb/s bi-directional data links
•Hot-pluggable SFP footprint
•Extended case temperature range
•Fully metallic enclosure for low EMI
•Low power dissipation
•Compact RJ-45 connector assembly
•Access to physical layer IC via 2-wire serial bus
•1000 BASE-T operation in host systems with SERDES interface
•1000Mbps compliant in host systems with SGMII interface
| Product Name | 1000BASE-T SFP Transceiver Module (Copper, 100m, RJ-45) |
| Product No | SFP-GES-TD |
| Date Rate | 1000Mbps |
| Form Factor | SFP |
| Power Consumption | < 1W |
| Cable Type | Copper |
| Media | Cat 6/Cat 6a |
| Temperature | 0 to 70°C (32 to 158°F) |
| Connector | RJ-45 |
| DDM/DOM | Not Supported |
| Cable Distance | 100m |
