| Product Name: | 1.25G SFP EX 1310nm 40Km LC DDM Transceivers |
| Product No: | SFP-24SM31-40D |
| Date Rate: | 1.25Gbps |
| Wavelength: | 1310nm |
Overview
SFP 1.25G SMF Tx1310nm 40km LC DDM
The SFP transceivers are high performance, cost effective modules supporting data rate of 1.25Gbps and 40km transmission distance with SMF. The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472 digital diagnostics functions.
【 Specification 】
Main Feature:
• Supports up to 1.25Gbps bit rates
• Hot-pluggable SFP footprint
• 1310nm FP laser and PIN photo detector, Up to 40km for SMF transmission
• Compliant with SFP MSA and SFF-8472 with single LC receptacle
• Compatible with RoHS
• Single +3.3V power supply
• Real Time Digital Diagnostic Monitoring
• Operating case temperature:Standard: 0 to +70°C; Industrial: -40 to +85°C
| Product Name | 1.25G SFP EX 1310nm 40Km LC DDM Transceivers |
| Product No | SFP-24SM31-40D |
| Date Rate | 1.25Gbps |
| Wavelength | 1310nm |
| Reach | 40km |
| Source | DFB + PIN |
| Temperature | 0 to 70°C (32 to 158°F) |
| TX Power | -5 ~ 0dBm |
| Receiver Sensitivity | < - 23dBm |
| Media Type | SMF |
| Connector | LC Duplex |
| DDM/DOM | Supported |
