| System Power Supply: | 11–14 V DC, 2 A |
| Ports: | 4xGE+1xPOTS+1xUSB+2.4G/5G WIFI |
| Optical Connector: | SC/UPC |
| Wavelength: | TX: 1310nm, RX: 1490nm |
| Model | Configuration | Dimension/pcs | ||||
| LAN | Telephone | Wifi | CATV | Firmware | ||
| EG8247W | 4GE | 1pots | 2.4G*5.8G | NO | English | 370*175*115mm/1kgs |
| 【 Specification 】 | |
| Device Parameters | |
| Working environment | Operating temperature: 0ºC to 40ºC |
| Environment humidity: 5% to 95% (noncondensing) | |
| Static power consumption | 9.7 W |
| Power specifications | Power adapter input: 100 to 240 V AC, 50–60 Hz |
| System power supply | 11–14 V DC, 2 A |
| Network-side Port | GPON |
| User-side Ports | 4xGE+1xPOTS+1xUSB+2.4G/5G WIFI |
| Indicators | POWER/PON/INTERNET/USB/WLAN |
| Dimensions(length x width x height) | 295 mm x 215 mm x 25 mm |
| Weight | About 500 g |
| Interface Parameters | |
| GPON Port | • Class B+ |
| • Receiver sensitivity: -27 dBm | |
| • Overload optical power: -8 dBm | |
| • Wavelengths: US 1310nm, DS 1490nm | |
| • Wavelength blocking filter (WBF) of G.984.5 | |
| • Flexible mapping between GEM Port and TCONT | |
| • GPON: consistent with the SN or password authentication defined in G.984.3 | |
| Ethernet Port | • Ethernet port-based VLAN tags and tag removal |
| • 1:1 VLAN, N:1 VLAN, or VLAN transparent transmission | |
| • QinQ VLAN • Limit on the number of learned MAC addresses | |
| • MAC address learning | |
| • Auto-adaptive 10 Mbit/s, 100 Mbit/s or 1000 Mbit/s | |
| POTS Port | • G.711A/μ, G.729a/b, and G.722 encoding/decoding |
| • T.30/T.38/G.711 fax mode | |
| • DTMF | |
| • Emergency calls (with the SIP protocol) | |
| USB Port | • USB2.0 |
| • FTP-based network storage | |
| • File/Print sharing based on SAMBA | |
| • DLNA function | |
| WLAN | • IEEE 802.11 b/g/n (2.4G) |
| • IEEE 802.11 a/n/ac (5G) | |
| • 4 x 4 MIMO (2.4G) | |
| • 4 x 4 MIMO (5G) | |
| • Antenna gain: 5 dBi | |
| • WMM/Multiple SSIDs/WPS | |
| • Air interface rate: 300 Mbit/s (2.4G), 867Mbit/s (5G) | |
