PX20++ Optical Module FTTH Network 9db 1.25G PX20++ Epon Olt Sfp

Overview

About Product

PON OLT PX20+ PX20++ PX20+++ is an SFP packaged hot-swappable optical module (compliant with IEEE 802.3ah 1000BASE-PX20+) used to connect optical data communication links. It adopts a single-fiber bidirectional design, and the uplink and downlink rates can reach up to 1.25Gbps, which is widely compatible with the market. Mainstream brand OLT equipment.

P/Ns Description

EPON OLT PX20++ EPON OLT PX20++ Diplexer, 20km, Tx 1490nm 1.25G, Rx 1310nm 1.25G, SFP form-factor, SC/UPC receptacle connector,  TX Power 7~10 dbm.

【 Specification 】

Main Feature:

●1. Single Fiber Transceiver with single mode SC receptacle ●2. 1490nm continuous-mode transmitter with DFB laser ●3. 1310nm burst-mode receiver with APD-TIA ●4. Single 3.3V power supply ●5. Reset burst-mode receiver design

●2. Burst mode signal detect output which is LVTTL compatible. ●7. Burst mode received signal strength indication (RSSI) output ●8. 20Km Reach 30dB link budget ●9. Complies with huawei,zte,fiberhome,bdcom OLTs ●10. Operating case temperature: Standard : 0 to +70°C
