Overview
Fiber Optic Multifunction
Distribution Box
fiber junction box
Product Description
IP 68 FTTH box
Feature:
•Integrated with flap-up splice cassette.
•IP68 with nice sealing.
•Pole mounting or wall mounting are optional.
•middle 2 inlet port for un-cut cable diameter from 10−17.5mm.
•7 other output cable port for cable diameter from 8-17.5mm.
Installation instruction procedures:
1)Strip the cable.
2)Open the closure.
3)Install the un-cut cable.
4)Protect the un-cut cable.
5)Introduce the cut cable into the splice tray.
6)Splice and store fibers.
7)Fixing cables.
8)Close and seal the closure.
9)Install the fiber closure.
| Product name | 144 core Fiber Optic | Protection grade | IP68 |
| Distribution Enclosure | |||
| Operating Temperature | -40℃~60℃ | Product Size | 410*240*130 mm |
| Installation type | wall-mount or pole mount | Port | 4 inlet port / 4 ftth drop cable port |
| Max capacity | 12F/tray, max capacity 144F(12 trays) | Net weight | 4.6kg |
| Material | Strengthen Polymer Plastic | Color | Black |
